VATN Monochrome LCD Display

CNK is China VATN Monochrome LCD Display supplier. We have the most complete production facilities and the most professional team. We insist on providing customers with the best services and the most suitable production solutions. VATN Monochrome LCD Display offer a wide viewing angle of up to 160 degrees, offering clear visibility from different positions.

Send Inquiry

Product Description

The VATN Monochrome LCD Display is a type of liquid crystal display (LCD) technology commonly used in electronic devices such as digital clocks, thermometers, and various consumer electronic products. These displays are popular due to their low power consumption, high visibility, and reliability.

Specification

LCD Size ：115.0(W ) × 44.5(H) × 2.85MAX (T) mm
Backlight Size：135.0(W ) × 39.5(H) × 2.8 (T) mm
Display View Area：112.0(W) ×37.5(H) mm
LCD Type ：HTN /POSITIVE/TRANSFLECTIVE
View Angle ：6 O’clock
Working temperature: -0~50C
Storage temperature: -10~60C
Operating voltage: 4.8V
Driving method:1/8 duty,1/4 bias

Here are some features of VATN Monochrome LCD Display:

Viewing angle: offer clear visibility from different positions.
High contrast: VATN Monochrome LCD Display provide high contrast, even in low ambient light conditions, which provides clear readability and reduces power consumption levels.
Low power consumption: They consume very low power, making them ideal for battery-powered devices.
Operating temperature: VATN Monochrome LCD Display are capable of operating in extreme temperature conditions.

Porduct Dateils
